LIVE MIX LIFE MAX
LiveMixer is designed through current-gen content creators, who need motherboards with great connectivity for streaming and other auxiliary devices. Also, its reliable performance allows us to provide wonderful contents and budget our time.
Broadcasting
Users will never run short. Hook up every peripheral, whether it’s mice, keyboards, microphones, headsets, multiple cameras, fill-lights, macropads, and much more.
Content Creation
Various content creator needs motherboards with superb reliability, cutting-edge performance and an extended connectivity mix for the many auxiliary devices.
- Content Creator
- Video Editing
- Photo Editor
- Game Development
Multiple Streaming Devices
We tested many video capture devices with different interfaces in order to provide the most stable system for content creators.
* Para garantir que o dispositivo AVerMedia funcione corretamente, atualize para o firmware e software mais recente através do aplicativo AssistCentral, do site oficial da AVerMedia, e reinicie o sistema.
- HD60 S
- HD60 S+
Overview
Effectiveness and Uniqueness
Provides stability and unique features enhancing effectiveness.
-
14 + 1 + 1 power phase with Smart Power Stage(SPS) and Nichicon 12K capacity.
Optimized VRM design for solid performance
Featuring sturdy components and completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well.
SMART POWER STAGE(SPS)
Dr.MOS design features the latest SPS (Smart Power Stage) technology. It’s optimized for monitoring current and temperature of each phase, thus delivering smoother and neater power to the CPU with enhanced performance and OC capability.
* Vcore onlyNICHICON 12K CAPICITY
Offers 20% longer lifespans and provides more stability and reliability.
* VRM only2oz Copper PCB
2 ounce copper inner layers that provide stable signal traces and power shapes! Delivering lower temperature and higher energy efficiency for overclocking.
-
![Blazing M.2[PCIe Gen5 x4]](img/svg/02.png)
Blazing M.2[PCIe Gen5 x4]
Blazing Fast Data Transfer and Great Heat Dissipation
Accommodates the latest PCI Express 5.0 standard to perform twice the bandwidth compared to previous generation, with a breathtaking 128Gb/s transfer speed.
MULTI-LAYER M.2 HEATSINK
Lower the temperature of your high-speed SSD to perform better and more stably.
ANTI-DROP SCREW DESIGN
Tired of dropping screws or screws missing inside chassis? The enhanced M.2 heatsink with anti-drop screw design makes installation process more easily and eliminates risk of missing screw and could be installed easily.
-
Ultra USB Power
Stable power and better sound experience!
Provides stable power and better sound experience! Ultra USB Power provides 5V power transformed from +12V power rail, whose voltage drop will be much lower than the +5V from the PSU under heavy loading, and prevents noise from other devices or RGB LED.
-
PCIe 5.0 + Surface-Mount Tech
Compares to conventional DIP style PCIe slot, the SMT type PCIe slot improves signal flow and maximize stability under high speed, a key breakthrough to fully support the lighting speed of the latest PCIe 5.0 standard.
The latest PCI Express 5.0 is capable to perform a breathtaking bandwidth of 128GBps, ready to unleash the full potential of future high end graphic cards. -
Conector de Sinal eDP Embutido
Suporta o Kit de Painel Lateral 13.3” da ASRock
* O Kit de Painel Lateral de 13.3" da ASRock não está incluído na embalagem da placa-mãe.
Um conector de sinal eDP está incluso nas placas-mãe ASRock selecionadas e suporta duas funções simultaneamente - energia e transmissão de sinal digital de imagem. O conector reserva espaço para atualização, com o exclusivo Kit de Painel Lateral de 13,3" da ASRock. O tamanho ideal do Painel Lateral de 13,3" será perfeitamente compatível com o gabinete de formato padrão e os usuários podem facilmente montar um display LCD dentro do PC, adicionando uma sub-tela para monitorar o status do PC ou assistir vídeos, fazer streaming ou trabalhar em tarefas personalizadas. Todo esse novo conceito de personalização permite novas possibilidades de design - duplicando a produtividade ou o entretenimento.
* O Kit de Painel Lateral de 13.3" da ASRock não está incluído na embalagem da placa-mãe.
Features Make Better
Optimizes your user experience.
-
DDR5 Memory
Supports DDR5 memory with max. 128GB capacity. -
23 USB Ports
Provides great connectivity to multiple USB devices. -
Dragon 2.5G LAN
Fulfills requirement of content creators and high-quality streaming media. -
Polychrome Sync
Allows users to synchronize RGB LED devices and create their own unique lighting effects. -
Nahimic Audio
Offers you the most engaging listening experience, vibrant and rich with details. -
Auto Driver Installer
Allow users to download and install all necessary drivers automatically.
